Z-15026001 AirPower AP5 Pneudraulic Threaded Insert Tool

The AP5 Pneudraulic Threaded Insert/Rivnut Installation Tool from Applifast is the highest powered tool in the AirPower Series lineup. With over 6,000 Lbs. of pulling force, the AP5 sets challenging 1/2’’ hex inserts with ease - consistently every time.

The AirPower5 pneudraulic professional threaded insert/Rivnut installation tool from Applifast is a proven robust game-changer with sophisticated ergonomics with a simple design for continuous reliable use in demanding industrial conditions.

The spin-pull-spin feature saves time and money with fast, semi-automated fastener installation. A quick, interchangeable mandrel system makes changing mandrel sizes easy and efficient without using additional tools. The multi-functional trigger can be actioned with one or two fingers for hours of comfortable use. A composite body keeps the operator’s hands warm and prevents scratching of assembly materials. User-friendly ergonomics with a simple design for continuous, reliable use in demanding industrial conditions make the AP5 a favourite with manufacturing professionals.

Capacity: M6-M12 | 1/4''-20 to 1/2''-13

Aluminum, Steel, Stainless Steel

Weight: 2.262 Kg | 4.986 Lbs.

Dimensions: 280 mm x 290 mm x 120 mm | 11.0’’ x 11.4’’ x 4.72’’

Stroke: 8 mm | 0.31’’

Pressure Required: 5-7 Bar | 80-100 PSI

Traction Power: 27.5 kN | 6,069 Lbf.

Mandrels Available: M6, M8, M10, M12 | 1/4''-20, 5/16''-18, 3/8''-16, 1/2''-13
